PostgreSQL with TLS Client Auth

Configure postgresql.conf to enable ssl and configure a server key and certificate.

Server Certificate

Create a self-signed certificate pair. Put them in ./tls

openssl req -new -x509 -days 3650 -nodes -text -out server.crt -keyout server.key -subj “/CN=server”

Client Certificates

openssl req -new -x509 -days 3650 -nodes -text -out client.crt -keyout client.key -subj “/CN=client”

postgresql.conf

ssl = on
ssl_key_file = '/tls/server.key'
ssl_cert_file = ‘/tls/server.crt’

We want to use self-signed client certificates that get verified. Put copies of each client certificate (NOT key) into the ca.crt file, eg.

cat client.crt >> tls/ca.crt

Add to postgresql.conf

ssl_ca_file = ‘/tls/ca.crt’

pg_hba.conf

This will require every connection to require a client certificate.

hostssl all all all cert

docker-compose.yml

This will mount the `./tls` folder into the image.

version: '3.7'

services:
  db:
    build: build/postgres
    environment:
      LANG: 'en_GB.UTF-8'
      LANGUAGE: 'en_GB.UTF-8'
      LC_ALL: 'en_GB.UTF-8'
      POSTGRES_DB: "${POSTGRES_DB:-postgres}"
      POSTGRES_PASSWORD: "${POSTGRES_PASSWORD?REQUIRED}"
      POSTGRES_USER: "${POSTGRES_USER:-postgres}"
    volumes:
      - "${CONTAINER_VOLUME?REQUIRED}/${SERIAL?REQUIRED}/postgres:/var/lib/postgresql/data:rw"
      - "${CONTAINER_VOLUME?REQUIRED}/${SERIAL?REQUIRED}/pg_socket:/var/run/postgresql:rw"
      - "${PWD}/tls:/tls:ro"
    restart: always
    ports:
      - "${PORTBASE?REQUIRED}32:5432"

Locales

Using Dockerfile to build with, we can specify the locale to use, in our case en_GB.UTF-8

FROM postgres:9.6
RUN localedef -i en_GB -c -f UTF-8 -A /usr/share/locale/locale.alias en_GB.UTF-8
ENV LANG en_GB.utf8

Connecting with psql

PGSSLKEY=client.key PGSSLCERT=client.crt psql --host 127.0.0.1 --port 5432 -U client -d postgres

psql --host 127.0.0.1 --port 5432 -U client -d “sslkey=client.key sslcert=client.crt dbname=postgres”

Evidence

select pg_ssl.pid, pg_ssl.ssl, pg_ssl.version,
           pg_sa.usename, pg_sa.client_addr
           from pg_stat_ssl pg_ssl
           join pg_stat_activity pg_sa
             on pg_ssl.pid = pg_sa.pid;

 pid | ssl | version | usename  | client_addr
-----+-----+---------+----------+-------------
  63 | t   | TLSv1.2 | postgres | 172.23.0.1
(1 row)
